High Voltage MCU

High Voltage MCU for a lot of Motion Control technologies

  • Pre-driver for external half-bridges / Peak Power up to 10 W
  • Built-in star point generation
  • Space-Vector commutation
  • Back EMF detection with Multi-Threshold Comparators
  • Direct MOSFET driver with High-Voltage-Ports



HVC-B



pdf BLDC_control_presentation_2010 1.112 KB
pdf HVC2480B_8Bit_Microcontroller_for_Direct_12V_Operation_1AI 483 KB
pdf HVC2480B_High_Voltage_MCU_for_Direct_12V_Operation_pi 475 KB
pdf HVC2480B_High_Voltage_MCU_for_Direct_BLDC_Motor_Control_pi 354 KB
