R32C 32-Bit MCUs

Renesas R32C111

The R32C microcontroller series extents the M16C platform with the performance of 50MHZ 32-Bit core. Mathematical functions like FPU, 32-Bit multiplier, barrel shifter and MAC operation in one cycle for DSP functionality. This series incorporates various peripheral functions suitable for industrial application, communication equipment, home appliances, PC peripherals und digital consumer electronics
  • Up to 1MByte on-chip embedded Flash
  • CAN, SPI, UARTs, I2C
  • 26ch 10-Bit ADC
  • 50 MHz with PLL
  • Single wire E8a and E30a debug interface
  • Low cost development environment
  • Renesas IDE and C-Compiler (60 day full version, then 64k code size limit)
Model  H8S/2462  H8S/2463  H8S/2472
Package  64LQFP 10x10mm
80LQFP 12x12mm
100LQFP 14x14mm 		 100LQFP 14x14mm
144LQFP 20x20mm 		 100LQFP 14x14mm
144LQFP 20x20mm
Flash   512KB )*  1MB )*  1MB )*
SRAM  63KB )* 63KB )*  63KB )*
CAN  ---  ---  1/2ch x 32 slot buffer
ADC  10-Bit x 26  10-Bit x 26  10-Bit x 26
I²C/SIO  9  9  9

)* maximum values

The R32C Series

R32C
  • High Performance 32-Bit MCU
  • Up to 50MHz over the range 3V - 5V
  • FPU, MAC, 32-Bit barrel shifter and multipier
  • DMA – Direct memory access
  • Voltage detection POR/LVD
  • Low voltage, low power
  • Compatibility between the complete series
  • Pin and function compatible to M16C series

R32C S/W Development Support

Manufacturer  Software

Renesas

 High performance embedded Workshop, Compiler

GLYN Evaluation Boards

Content:

  • CPU Board
  • Connection Cable (USB Cable)
  • Connector USB, E8a, E30a
  • HEW
  • Renesas C/C++ Compiler
  • Program Examples
  • Quick Start Guide

R32C

R32C/111 (R5F64112FB)



Data Sheet:
R32C/111

Evaluation Boards:
EVBR32C111GP
EVBR32C111-CARRIER-USB

Debug-Tools: E8A  und E30A



R32C/116 – R32C/117 – R32C/118 (R5F64169PFB, R5F64179PFB, R5F64189PFB)

Data Sheet:
R32C/116
R32C/117
R32C/118

Evaluation Boards:
EVBR32C118GP

Debug-Tools: E8A   und E30A
